Here are the frequently asked questions for Stream Deck Studio.
What software is needed for Stream Deck Studio?
Stream Deck Studio requires Bitfocus Buttons, which is key to enabling the device’s advanced routing, control, and monitoring capabilities. The device also works well with Bitfocus’s open-source software, Companion, which is excellent but lacks the advanced features of Buttons.
What is Bitfocus Buttons?
Bitfocus Buttons is a powerful software designed for professionals who need advanced routing, scaling, and management capabilities in live production environments.
For more information, click here.
Which systems, services, and hardware does Stream Deck Studio work with?
Through Buttons, Stream Deck Studio works with a long and growing list of compatible equipment.
Can multiple Stream Deck Studio devices be linked together for large-scale productions, and how do they sync?
Yes! With Bitfocus Buttons software, multiple Stream Deck Studio devices can be controlled simultaneously and act as a single, larger grouping of keys and dials.
How customizable are Stream Deck Studio keys?
Completely! Each key is a full-color TFT LCD screen that can display icons, images, and/or text of your choosing. Customization is done in Bitfocus Buttons software.
What can I connect to the front USB-C port?
Any of our bus-powered Stream Deck variants, from Stream Deck Mini to Stream Deck XL, Stream Deck +, or even Stream Deck Pedal.
How does Stream Deck Studio connect to a broadcast system?
Stream Deck Studio connects to broadcast setups using either of two methods: an IP-based connection via the RJ45 10/100Mbps Ethernet port with PoE+ power, or a USB connection through the rear USB-C port. If PoE+ is not used, power can be supplied via a USB-C PD 3.0 power supply (minimum 9 V, 3 A).
Does Stream Deck Studio feature onboard processing?
To keep up with rapid changes in the broadcast industry, and accommodate any setup large or small, Stream Deck Studio relies on Bitfocus Buttons for Windows and Mac. This powerful software handles all the processing, so Stream Deck Studio itself does not require onboard processing.
How does Buttons differ from Companion?
While Companion is a powerful open-source broadcast tool, Buttons is designed with more advanced features like scrollable sections, user-authenticated profiles, dynamic presets, and built-in scaling for large installations. It’s tailored for professionals who need a more robust, scalable solution.
Where can I get more information on Buttons?
Our friends at Bitfocus know everything there is to know about Buttons. If you have any questions, get in touch with them.
What kind of support is available?
Bitfocus provides comprehensive software assistance for Buttons, ensuring you have all the help you need for smooth operations. For hardware-related issues, reach out to Elgato Support.
